Nexus-Box 3.1
Designed with versatility and simplicity in mind, it seamlessly delivers reliable power to all essential peripherals – including computers, receipt printers, scales, and barcode scanners – via a single, elegant and safe solution.
PowerSafe Mode
Smart, customizable shutdown mode for energy savings during off-hours
Smart USB Hub
Integrated powered USB 2.0 Hi-Speed hub for peripheral connectivity, including the ability to individually power on/off each port
Failsafe DFU
(device firmware upgrade)
Remote and safe firmware upgrade with automatic fallback to previous version if upgrade fails
Integrated RGBW LED Driver
Dual-channel driver for ambient and status lighting – no external unit needed
Easy and intuitive control with Serial-over-USB
System Watchdog
Monitors POS operation and triggers automated restart in case of system failure (e.g. frozen computer)
Bluetooth Beacon
Integrated BLE 5.0 module supporting configurable iBeacon protocol for proximity services
Fully programmable iBeacon interface via Serial-over-USB
Status LEDs
Status LEDs (power status, fault indication, I/O status) visible through
housing for easy maintenance
Intuitive and easy-to-use API for full control and custom configuration
over Serial-over-USB
Fully programmable boot/shutdown/restart sequence – each peripheral
can be individually powered up and down based on a timer
Device status report enables remote monitoring of all devices
Isolated I/O
24 V isolated input and output for secure connection to auxiliary devices (e.g. exit gates)
easy Java SDK
24 V, up to 350 W
Up to 3 × 12 V
Up to 1 x 24 V
IP 22
194 × 104 × 31 mm (L × W × H)
4 Mounting points
950 g
IP 22
Galvanized sheet metal housing
0 °C to +40 °C
